5720 Series

The following diagrams illustrate the components on the front panels of the 5720 Series switches.

Note

Note

In addition to the regular fixed ports, all 5720 Series switches have two QSFP28/QSFP+ Universal Ethernet ports and a Versatile Interface Module (VIM) slot. If you install a VIM, the switch reserves the Universal Ethernet ports for advanced features. If you do not install a VIM, the switch reserves two internal VIM ports for advanced features and you can use the Universal Ethernet ports as regular ports. If you do not require advanced features, you can use the Universal Ethernet ports as regular ports. For more information about using the advanced-feature-bandwidth-reservation boot flag to configure the functionality of these ports, see Advanced Feature Bandwidth Reservation.

When used as regular ports, the port speed is 40 Gbps as a single channel port. Although the maximum supported single channel port speed is 40 Gbps, the ports can be channelized to operate as four 10 or 25 Gbps channels.

5720-24MW

The following diagram illustrates the components of the front panel of the 5720-24MW switch.

Click to expand in new window
View of the 5720-24MW front panel
  1. USB Micro-B console port
  2. USB Type-A port
  3. System LEDs
  4. Mode button
  5. 2 Universal Ethernet/QSFP28 ports (unpopulated)
  6. VIM Slot. Port numbering depends on the type of VIM installed in the slot.
  7. 24 100M/1/2.5/5GbaseT 802.3bt PoE (90W) full-duplex (FDX), MACsec-capable ports

5720-48MW

The following diagram illustrates the components of the front panel of the 5720-48MW switch.

Click to expand in new window
View of the 5720-48MW front panel
  1. USB Micro-B console port
  2. USB Type-A port
  3. System LEDs
  4. Mode button
  5. 2 Universal Ethernet/QSFP28 ports (unpopulated)
  6. VIM Slot. Port numbering depends on the type of VIM installed in the slot.
  7. 48 100M/1/2.5/5GbaseT 802.3bt PoE (90W) full-duplex (FDX), MACsec-capable ports

5720-24MXW

The following diagram illustrates the components of the front panel of the 5720-24MXW switch.

Click to expand in new window
View of the 5720-24MXW front panel
  1. USB Micro-B console port
  2. USB Type-A port
  3. System LEDs
  4. Mode button
  5. 24 100M/1/2.5/5/10GbaseT full-duplex (FDX), MACsec capable ports with 802.3bt Type 4 PoE (90W)
  6. VIM Slot. Port numbering depends on the type of VIM installed in the slot.
  7. 2 Universal Ethernet/QSFP28 ports (unpopulated)

5720-48MXW

The following diagram illustrates the components of the front panel of the 5720-48MXW switch.

Click to expand in new window
5720-48MXW Front Panel
View of the 5720-48MXW front panel
  1. USB Micro-B console port
  2. USB Type-A port
  3. System LEDs
  4. Mode button
  5. 2 Universal Ethernet/QSFP28 ports (unpopulated)
  6. VIM Slot. Port numbering depends on the type of VIM installed in the slot.
  7. 48 100M/1/2.5/5/10GbaseT full-duplex (FDX), MACsec capable ports with 802.3bt Type 4 PoE (90W)

VIMs

  • 5720-VIM-6YE

    Versatile Interface Module that provides six 25GbE SFP28 MACsec-capable ports

  • 5720-VIM-2CE

    Versatile Interface Module that provides two 100GbE QSFP28 MACsec-capable ports

For more information about VIM modules, see ExtremeSwitching 5720 Series Hardware Installation Guide.

5720 Series Back Panel View

The following diagram illustrates the components of the back panel of the 5720 Series

Click to expand in new window
Back view of the 5720-24MW front panel
  1. SSD slot
  2. Fan modules
  3. 10/100/1000 BASE-T out-of-band management port
  4. Power supply slots
  5. Grounding lug
  6. Serial console port (RJ-45)
  7. Type-A USB port for management or external USB flash
